NVIDIA DeepStream SDK: Real-time AI Video Analysis

:554/stream1numsources=1 type=3: RTSP stream input. enable=1: Activates this source block. uri: Input stream URL. num-sources: Number of sub-streams in this block. gpu-id: GPU used for decoding. Each input source must be defined in a separate [sourceX] block. All inputs are sent to the multiplexer for batching Stream Multiplexing (nvstreammux) The nvstreammux plugin combines multiple input frames into a single batch for batched inference. All frames are resized to a common resolution. [streammux]batch-size=4width=1280height=720batched-pushtimeout=40000 batch-size: Must match the number of enabled [sourceX] entries. width, height: All frames are resized to this resolution before inference. batched-push-timeout: Time (in µs) to wait for frame alignment before pushing the batch. enable-padding: Maintains aspect ratio using padding (black bars). gpu-id: GPU used for muxing and buffer management. nvstreammux ensures that inference receives aligned batches, which improves model throughput and consistency. Inference Engine Configuration The nvinfer plugin runs deep learning models for object detection, classification, or segmentation using TensorRT. Models must be provided as .engine files, typically exported from ONNX, TensorFlow, or Caffe Basic inference setup: [primary-gie]enable=1model-engine file=./resnet18_detector.trtlabelfile-path=labels.txtbatchsize=4network-mode=2interval=0gie-unique id=1config-file-path=config_infer_primary.txt model-engine-file: Path to TensorRT .engine file. labelfile-path: Text file mapping class indices to names. batch-size: Must match streammux.batch-size. network-mode: 0 = INT8, 1 = FP32, 2 = FP16. interval: Frame skipping for inference. 0 = infer on every frame. config-file-path: Specifies network preprocessing, input layers, postprocessing, and scaling options. gie-unique-id: Required to link secondary GIEs. Models must be converted to .engine format using TensorRT CLI tools or DeepStream scripts from ONNX/Caffe/TensorFlow. Real-Time AI Analysis via CLI To execute a complete DeepStream pipeline directly from the terminal using a predefined configuration file. It allows users to run real-time inference, handle inputs and outputs, and control the processing flow without writing application code. To launch the pipeline: deepstream-app -c configs/deepstream_app_config.txt This command reads the configuration file and runs the pipeline, which may include video decoding, inference, object tracking, and rendering or output. For debugging or inspecting plugin behavior: deepstream-app -c configs/deepstream_app_config.txt --gst-debug level=2 This enables GStreamer debug logs to help track buffer handling, plugin state, and errors. To run on headless systems and output to a file instead of displaying video, configure the sink: [sink0]enable=1type=4sync=0codec=1bitrate=4000000output file=output.mp4 This setup disables display rendering and uses NVENC to write processed video to output.mp4 using H.264 encoding. Tracking Configuration DeepStream supports object tracking through nvtracker. The default uses KLT or IOU-based tracking. Configure via: [tracker]tracker-width=640tracker-height=480ll-lib file=/opt/nvidia/deepstream/deepstream/lib/libnvds_nvdcf_tracker.so tracker-width, tracker-height: Used for scaling tracking layer. ll-lib-file: Tracker algorithm (IOU, KLT, NvDCF). enable-batch-process: Enables batch inference from multiple sources. Trackers like NvDCF use motion and appearance features. KLT is CPU-based and slower; IOU uses bounding box overlap. Each detected object is assigned a unique ID that persists until the object leaves the frame. Performance and Latency Notes For 4 concurrent 1080p RTSP streams with detection models (e.g., YOLOv5 or SSD), DeepStream maintains >25 FPS per stream on an RTX 3060. To profile: nvidia-smi dmon Shows encoder, decoder, memory, and GPU utilization per second. Helps identify decode/infer bottlenecks To run with detailed inference and memory logging: deepstream-app -c configs/deepstream_app_config.txt -q Prints per-stream FPS, buffer latency, and model load times. Useful for validating pipeline health under load. Custom Inference + Metadata Access To build a programmatic pipeline (not using deepstream-app), use Python or C/C++ bindings via deepstream_python_apps. Basic Python snippet to access metadata: for frame_meta in batch_meta.frame_meta_list: for obj_meta in frame_meta.obj_meta_list: print(f'Object ID: {obj_meta.object_id}, Class: {obj_meta.class_id}') object_id: Persistent tracking ID from nvtracker. class_id: Model-predicted label index. confidence: Detection score. Additional fields include bounding box, timestamp, and custom user metadata.
